53″ Widh cap., (1) Cross belt sanding head, and (1) Combination head consisting of Contact Roller & Finishing Platen.
1st Head: Cross belt sanding head “Q” with Chevron inner belt, abrasive belt size 150 x 4,700 mm (6″ x 185″). Electronically controlled segmented finishing platen, with 54 segments each 25 mm wide (1″). Pressure on part edges can be adjusted infinitely variable. Abrasive belt speed infinitely variable 2 – 16 m/Sec (6 – 52 FPS). Driven by 13,5 kW (18,5 HP) motor. Oscillating air jet belt blower for abrasive belt cleaning, controlled by part size.
2nd Head: Combination head “C” with steel contact roller and finishing platen, segmented, with CPS II electro-magnetically control system. Abrasive belt speed variable 2 – 28 m/Sec (6 – 59 FPS). Driven by 15 kW (20 HP) motor. Abrasive belt can be operated clockwise and anti-clockwise. Oscillating air jet belt blower for abrasive belt cleaning, controlled by part size.
Feed system: Constant pass-line. Vacuum conveyor bed assembly with 3 kW (4 HP) suction fan inside machine frame. Variable feed speed conveyor belt speeds adjustable from 2,5 – 13 m/Min (6 – 42 FPM), 1 kW (1,3 HP) feed drive. Auto belt tracking. Part thickness 3 – 160 mm (1/8″- 6-5/16″). Motorized thickness adjustment with digital readout. Rubberized hold-down rollers.
Electronic brakes on sanding head motors, infeed emergency stop. Motor load meters for supervision of stock removal. Emergency stops front & back. Total power 34 kW. Space required 2,050 x 2,070 x 2,180 mm (81 x 82 x 86″). Gross weight approx. 3,600 kg (approx. 7,950 Lbs.)
