| Cast iron fixed table dimension | 27 ½” x 39.4” |
| Sliding table dimension | 126” x 15 ½” |
| Main saw blade diameter | 400mm (15.75”) |
| Main saw bore | 30 mm |
| Max. cutting height w/ blade at 90o | 4.13” |
| Max. cutting height w/ blade at 45o | 2 ¾” |
| Main saw motor | 7.5 HP (5.5 Kw) |
| Main blade speed | 3000/ 4000/ 5000 RPM |
| Scoring saw blade | 120 mm (4.72”) |
| Scoring saw blade bore | 20 mm |
| Scoring blade motor | 1 HP (0.75 kw) |
| Scoring blade speed | 8000 RPM |
| Cutting width | 51.2” |
| Cutting width adjustment | NC control |
| Blade tilting adjustment | NC control (0°~45°) |
| Main saw height adjustment | NC control |
| Scoring saw height adjustment | Motorized |
| Scoring saw direction adjustment | Motorized |
| Main blade speed show | Digital |
| Crosscut fence | Manual (Digital optional) |
| Dust collection system | 4.72” / 2.4” (120/ 60 mm) |
| Machine total weight | 2530 lbs. |
| Machine shipping weight | 2490 lbs. |
| Sliding table shipping weight | 433 lbs. |
| Machine shipping dimension | 130” x 57 ¼” x 44” |
| Sliding table shipping dimension | 131” x 19.3” x 14.3” |
