Specifications & Working Capacity:“X” Axis is 114″ (2,900 mm), “Y” axis 51″ (1,300 mm) when routing & 39″ (1,000 mm) when boring, “Z” axis stroke is 11″ (280 mm), max material thickness is 7″ (180 mm)
Positioning speed:“X” Axis 262 FPM (80 MPM),”Y” axis 131 FPM (40 MPM), “Z” axis 74 FPM (22.5 MPM); YASKAWA AC Servo motors in all (3) axes.
Comes with C-Axis
Worktable:(8) Vacuum hold-down support rails; (2) Adjustable vacuum pods per support; rails have pneumatic locking control, support rails slide on THK guides in the “X” axis for manual positioning;(8) Lifting bars to assist in loading/unloading heavy panels; (8) pop-up backstops, (8) pop-up front stops, (4) pop-up side stops, (2) pop-up center stops, which create (4) separate work zones (four 0/0 points).
Boring Block:(1) 5 HP (3 kW) motors, variable speed from 1,000 – 4,500 RPM with HSK F 63 adaptor; (30) Independent vertical boring spindles; (16) spindles on the “X” axis & (14) spindles in “Y” axis. (10) Horizontal spindles with, (3+3) in “X” axis & (1+1) in “Y” axis
Machining Units: …this machine has (2) routers(1) Vertically mounted 15 HP (11 kW) electro-spindle router, inverter driven, variable speed from 1,000 – 18,000 RPM, with HSK F 63 adaptor
This unit is currently out of stock, but we have comparable machines in used CNC Equipment. Here are few similar products in used CNC Equipment
