Features and Specifications:
- 2004 Model
- Working width 1100 mm/ 43″
- Working height 3 ÷ 160 mm
- Sanding belt width 1120 mm
- Sanding belt length 2200 mm
- 220V, 3Phase and 60 Hz
- Main motor power 7,5 kW
- Feed speeds (2) 4,5/9 m/min
- Feed motor power 0,3 / 0,5 kW
- Compressed air consumption 15 / 30 NI/min.
- Operating pressure 6 Bar
- Dust requirements 2500 / 5000 m3 /h
- Variable speed belt
- Auto thickness detection
- 1st head Steel drum
- 2nd head pad
- Powered raise & fall of the worktable with 4 large columns
- Electronic digital readout of working height
- Feed belt hardness 70 Sh
- Sanding belt tensioning rollers with fulcrum in the centre horizontally pivoted to compensate for tapered belts
- Electronic tracking of sanding belts
- Floating rubber coated (40 Sh) pressure rollers
- Automatic disk brake system
- Two feed speeds
- Manual star/delta starter for main motor
- Safety stock removal limit switch
- Front safety bar
- Overload protection on main motor
- TC VERSION
Combined operating head including: Grooved steel contact roller ø 140 mm, ground and polished, with micro metric height adjustment. Platten complete with rigid pad with micro metric adjustment.
- RT VERSION
First operating head: Grooved steel contact roller ø 160 mm, ground and polished, with micro metric height adjustment. Second operating head: Platten complete with rigid pad with micro metric adjustment.
- RR VERSION
First operation head: Grooved steel contact roller ø 160 mm, ground and polished, with micro metric height adjustment. Second operating head: Rubber coated contact roller mø 190 mm 45 Sh with micro metric adjustment.
- RTC VERSION
First operation head: Grooved steel contact roller ø 160 mm, ground and polished, with micro metric height adjustment. Second operating head: Combined head including grooved steel contact roller ø 140 mm, ground and polished, with micro metric height adjustment. Platten complete with rigid pad with micro metric adjustment.
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
