Features and Specifications:
- 1996 Model
- 230/460V, 60 Cy, 3 Ph.
- 96″ L x 64″ W x 128″ H
- Weight: 4,500 Lbs (estimate)
- S/N 0996-0108
- 39-1/2″ Wheel dia., 25 HP main motor, 17-3/4″ max vert. cap., 17-1/4″ max. spacing of feed rolls, 8-1/2″ max. opening of feed rolls.
- 5 HP Hydraulic feed drive for feed speed rates from 10 – 166 FPM.
- 4″ Max. blade width, 21′ blade length, 1-piece cast iron body.
- 9″ high x 28″ long gravity roller
- Adj. width
- Tilting fence
- 4″ wide blade on machine
- 3 ½” wide bandsaw wheels x 20″ dia
- Approx. 8″ throat cap.
- Approx.17 ½” height cap
- No pit required
- Foot pedal
- Foot counting meter wheel
- 19 ½” dia saw wheel
- 17″ max. distance of feed roller to fence
- 6310 ft/min cutting speed
- 20 ½ ft min length of blade
- 21 ft max length of blade
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
Details
| Weight | 2041 kg |
|---|---|
| Dimensions | 96 × 64 × 128 in |
| Brand | Fortis |
| Model | DRPA 100 |
| Voltage | 230-460 |
| Phase | 3 |
| Serial | 0996-0108 |
