Coast Machinery Group

SCM Sliding Table Saw SI 400 Nova

SCM Sliding Table Saw SI 400 Nova

SKU: 580-4

CAD $23,500.00

Out of stock

Contact Mitch Brennan:
Call 6045562225 or
Intl. 1 (855) 556-5121 Ext.1
ASK ME

Features and Specifications:

  • This machine is in excellent condition, purchased New 6 Month Ago
  • Anodized aluminum sliding table with hardened steel guides
  • Self Braking Motor
  • Separate 1 hp scoring motor
  • Tilting arbor from 0 to 45 degrees
  • Mechanical tilt indicator
  • External scoring saw adjustment with stops
  • Slider locks anywhere to the right of the blade
  • Overhead mounted blade guard with dust outlet
  • Heavy industrial aluminum extrusion crosscut fence with flip stops
  • “EZ Dial” Adjustable split scoring blade assembly
  • Standard 1 year warranty (10 years on table guideway tolerances)
  • Separate hand wheels on front for lifting and tilt of blade
  • Eccentric Clamp
  • Electrical control panel tilted 25 deg. for ergonomics
Main Motor Horsepower 9 HP
Scoring Motor Horsepower 1 HP
Fixed Table Size 41″ x 25″
Height of Worktable 34.5″
Rip Capacity 51″
Max Length of Crosscut with Scoring 126″
Main Blade Diameter / Arbor 16″ / 1″
Scoring Blade Diameter / Arbor 5″ / 3/4″
Arbor Speed – main / scoring 4,000 / 8,500 RPM
Dust Outlets – main / overarm guard 5″ / 3.25″
Depth of Cut – 0° / 45° 5.5″ / 3.8″
Net Weight 2,200 lbs
Electrical Requirements 36 AMPS @ 220v, 3 ph
Dust Extraction 1100 CFM

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

Please call for more information.

Details

Brand

SCM

Model

SI 400 NOVA

Voltage

230 V

HP

9 HP

Phase

3

Serial

AB 228095

Manufactured Year

2017
