Used FlexiCAM Stealth CNC Router 5′ x 10′ Table

Specifications:

• Space-saving fixed table – moving gantry design for small machine footprint
• Single structure welded, stress relieved and machined all-steel baseframe, gantry and gantry feet
• Steel structures are reinforced with heavy ribs to resist flex and dampen vibrations
• Each machine design is efficiently optimized and validated by using Finite Element Analysis (FEA) to ensure quality, performance, and safety
• Open machine bed for easy loading and unloading by forklift or overhead crane
• High preload profiled linear bearings with cover strips on all axis
• Brushless digital A/C servo drives and motors on all axis
• Dual side drive and synchronised X-axis; no twist under load like applicable to a single center-mounted ballscrew or cantilevered design
• Rack and pinion drive system on X and Y axis
• High precision ballscrew on Z axis (anchored at both ends)
• Low-backlash planetary gear boxes
• Fully closed cable carriers prevent the cables from damage by chips and fine dust
• High quality, shielded cables for energy chains are a guarantee of reliability
• Z-axis clearance 200 mm, optional 280 mm
• Z-axis travel 280 mm
• Maximum axis speed 60 m/min (1,500 mm/s) depending on controller, motors and drives
• Vacuum Pumps Included

SHIPPING: FULL TRUCK LOAD

• Serial No: 08036024
• MFG Year: 2008
• 3 x 230 V
• 50/60 Hz
• 3 Phase
• Short nose 8.9 HP
• S1 Continuous 10.7 HP

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge. Please call for more information
